Plasma TV Y,Z,X, & Buffer Board

Plasma TV Buffer Boards – Complete Buying Guide

Plasma televisions use several specialized circuit boards to generate and control picture output. Among the most important are the Buffer Boards, also known as Y Buffer Boards, Scan Buffer Boards, Upper Buffer Boards, and Lower Buffer Boards. These boards work together with the Y-Sustain and Z-Sustain circuits to drive the plasma display panel and produce accurate image reproduction. :contentReference[oaicite:1]{index=1}

At Great Bharat Electronics, we stock original plasma TV buffer boards for Samsung, LG, and Panasonic plasma television models. Every board is thoroughly tested before dispatch and supplied ready for installation.

What Does a Plasma TV Buffer Board Do?

The buffer board receives video signals from the sustain circuitry and distributes them to thousands of display cells within the plasma panel. These signals control the illumination of individual pixels, enabling the television to display clear images, colors, and motion.

A malfunctioning buffer board can interrupt these signals, resulting in visible display defects and picture failures. In many plasma televisions, separate upper and lower buffer boards are used to control different portions of the display. :contentReference[oaicite:2]{index=2}

Common Names Used for Buffer Boards

Customers often search using different terms. These parts may be referred to as:

Buffer Board, Plasma Buffer Board, Y Buffer Board, Y-Drive Board, Scan Drive Board, Scan Buffer Board, Upper Buffer Board, Lower Buffer Board, Plasma Display Driver Board, Plasma Scan Board, Plasma TV Picture Board, Plasma Panel Driver Board, YDRV Board.

Symptoms of a Defective Plasma Buffer Board

• Horizontal colored lines on screen
• Upper half display missing
• Lower half display missing
• Vertical picture distortion
• No image on part of screen
• Black bands across display
• Picture flickering
• Image breakup and pixel errors
• No picture while sound works normally
• Plasma TV powers on but display remains blank

Compatible Brands Available

Our collection includes original and compatible plasma TV buffer boards for:

• Samsung Plasma TVs
• LG Plasma TVs
• Panasonic Plasma TVs

Many popular plasma models from 42-inch, 43-inch, 50-inch, 51-inch, 60-inch, and 64-inch series are supported through our inventory. :contentReference[oaicite:3]{index=3}

How to Match the Correct Buffer Board

To ensure compatibility, compare:

• TV model number
• Buffer board part number
• PCB board number
• Sticker codes and revisions
• Upper/Lower board configuration

Never order solely based on TV screen size. Manufacturers often use multiple board versions within the same television series.

Why Buy from Great Bharat Electronics?

• Original tested plasma TV spare parts
• Expert compatibility verification
• Support for Samsung, LG & Panasonic models
• Secure packing and nationwide delivery
• Technical assistance before purchase
• Fast dispatch across India

Customers Also Search For

Plasma TV Y Sustain Board, Z Sustain Board, X Main Board, Y Main Board, Plasma TV Motherboard, Plasma TV Power Supply Board, Plasma Scan Drive Board, Plasma Display Driver Board, Plasma TV Repair Parts, Samsung Plasma TV Spare Parts, LG Plasma TV Spare Parts, Panasonic Plasma TV Spare Parts, Plasma TV Picture Problem Solution.

Frequently Asked Questions
